Inversor solar MUST PI1500 LV do catálogo 2026
MUST EnergySolução durável
Inversores de 110 VMUST

PI1500 LV

Inversor solar MUST PI1500 LV da linha 2026, com potência de 300–2000 W e saída CA de 120 V. Consulte a ficha completa para comparar modelos, proteções, comunicação, dados elétricos e dimensões.

Potência300–2000 W
Saída CA120 V
Bateria12/24/48 V CC
Forma de ondaSenoidal pura
Solicitar orçamento Ficha técnica PDF

Principais parâmetros da série

PARÂMETROS PRINCIPAIS
MODELOPI15-0312 LVPI15-0324 LVPI15-0612 LVPI15-0624 LVPI15-1012 LVPI15-1024 LVPI15-1512 LVPI15-1524 LVPI15-2012 LVPI15-2024 LVPI15-2048 LV
BATTERY DC INPUT
Input Voltage12VDC24VDC12VDC24VDC12VDC24VDC12VDC24VDC12VDC24VDC48VDC
Low Voltage Protect
Delay		2 seconds
Low Voltage
Warning		(PB)10.5VDC21.0VDC10.5VDC21.0VDC10.5VDC21.0VDC10.5VDC21.0VDC10.5VDC21.0VDC42.0VDC
 (LI)10.5VDC21.0VDC11.6VDC23.2VDC11.6VDC23.2VDC11.6VDC23.2VDC11.6VDC23.2VDC46.4VDC
Low Voltage
Protect		(PB)11.5VDC23.0VDC11.5VDC23.0VDC11.5VDC23.0VDC11.5VDC23.0VDC11.5VDC23.0VDC46.0VDC
 (LI)11.5VDC23.0VDC12.0VDC24.0VDC12.0VDC24.0VDC12.0VDC24.0VDC12.0VDC24.0VDC48.0VDC
Low Voltage
Restoring		(PB)12.5VDC25.0VDC12.5VDC25.0VDC12.5VDC25.0VDC12.5VDC23.0VDC12.5VDC23.0VDC46.0VDC
 (LI)12.5VDC25.0VDC12.8VDC25.6VDC12.8VDC25.6VDC12.8VDC25.6VDC12.8VDC25.6VDC51.2VDC
Over
Voltage
Protect		(PB)14.7VDC29.4VDC14.7VDC29.4VDC14.7VDC29.4VDC14.7VDC29.4VDC14.7VDC29.4VDC58.8VDC
 (LI)14.7VDC29.4VDC14.5VDC29.0VDC14.5VDC29.0VDC14.5VDC29.0VDC14.5VDC29.0VDC58.0VDC
Over
Voltage
Restoring		(PB)15.0VDC30.0VDC15.0VDC30.0VDC15.0VDC30.0VDC15.0VDC30.0VDC15.0VDC30.0VDC60.0VDC
 (LI)15.0VDC30.0VDC14.8VDC29.6VDC14.8VDC29.6VDC14.8VDC29.6VDC14.8VDC29.6VDC59.2VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power300W600W1000W1500W2000W
Peak Power600W1200W2000W3000W4000W
Output AC Voltage120V120V120V120V120V
Output AC Frequency60Hz60Hz60Hz60Hz60Hz
Output WavePure Sine Wave
Output Wave THD< 3%
PROTECTION
Battery Input ProtectionLow Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output
Protection		Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED DisplayRed: Error ; Green: System OK
LED Digital Display/Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USBUSB-A type (5V1A)NC
EFFICIENCY
Peak Conversion
efficiency		91%91%90%88%90%88%90%88%
OUTROS PARÂMETROS
MODELOPI15-0312 LVPI15-0324 LVPI15-0612 LVPI15-0624 LVPI15-1012 LVPI15-1024 LVPI15-1512 LVPI15-1524 LVPI15-2012 LVPI15-2024 LVPI15-2048 LV
ESPECIFICAÇÕES MECÂNICAS
Machine Dimension
(W*H*D)(mm)		205*125*61242*158*81291*220*83380.8*248*90
Package Dimension
(W*H*D)(mm)		228*102*176268*140*205330*147*267420*150*300
N.W(kg)11.72.64.5
G.W(kg)9.3 (8pcs)15 (8pcs)23 (8pcs)19 (4pcs)
OUTROS
Protection DegreeIP20IP20IP20IP20IP20IP20IP20IP20IP20IP20IP20
Working EnvironmentIndoor Fan cooling
Environmental
temperature		0~45°C
Ambient humidity20%-90%, No condensation
Altitude≤3000m
Standard Warranty2 year
CERTIFICAÇÕES E NORMAS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) ; CE-LVD(EN 62477-1/A11)

O preço depende do modelo e da configuração.
